The beverage industry, the processed food industry, the food industry, the industrial processing of oil, lubricants and fruit substances, and the dairy processing industry. The Blaudieck hose complies with FDA, BFR and EU food regulations.
BLAUDIECK SUPER CONDUCTIVE
A, B, C, D1 and D2 media classes are in compliance with EU Regulation 10/2011. These classes cover watery, fatty and oily foods; foods with a pH below 4.5; and foods containing up to 95% ethanol.
Two white stripes against a blue background, applied in a spiral pattern, with the following print: ‘Continental BLAUDIECK SUPER, glass/fork symbol, EC 1935/2004, Made in Germany, QR code’.
- inner layer: UPE, white, non-porous, without plasticisers, smooth with a black spiral charge-conducting strip
- reinforcement: synthetic fibres with steel spiral
- lining: NBR, blue, fabric texture, resistant to abrasion and ozone, with black spiral charge-conducting strip
- operating pressure: up to 16 bar / 232 psi
- temperature range: -30°C / -22oF to +95°C / +203°F to +110 °C / +230 °F (max. 60 minutes)
- with limited flow up to: +130 °C / +266 °F
further properties:
- charges are dissipated through the walls of the hose R < 109 Ω
- the hose is suitable for use in potentially explosive environments
- oil and grease resistant inner layer and lining
- recommended fittings PAGUFIX & PAGUCLAMP
- resistant to cleaning agents, disinfectants and chemicals in compliance with the Continental resistance list
