Products>Industrial hose>Steam hoses>DAMPF TRIX® 5000

DAMPF TRIX® 5000

Construction industry, Machinery and plant engineering, Tank trucks

Hot water, Steam, Water

3 red coloured axial markings on black cover “Continental DAMPF TRIX®
5000 – DAMPF / STEAM – PN 6 BAR / 87 PSI – Ω Made in Germany”

Inner lining: EPDM, black, non-porous, smooth
Reinforcements: Aramid
Cover: EPDM, black, smooth, abrasion resistant, from DN 25
upward fabric patterned, resistant to ozone, weather and UV
Working pressure up to: 6 bar / 87 psi
Temperature range: from -40 °C / -40 °F up to +120 °C /
+248 °F
Dampable up to: +164 °C / +327 °F
Further properties:
• Continuos temperature resistant
• Electrically conductive, R < 106 Ω/line
• Highly flexible

DOWNLOAD the catalog card
