Products>Industrial hose>Chemical hoses>ELAFLEX Type UTD

ELAFLEX Type UTD

Pressure hose for discharge in wet and dry hose usage. Also suitable
as reel hose provided the inner pressure reaches min. 0,5 bar to avoid
kinking.

Blue-white-blue bands every 0,5 mtr. Continuous embossing as per
example

Liquid and pasty chemical and petroleum

Inner lining: Ultra high molecular polyethylene UPE, white, with
conductive OHM spiral stripe, smooth bore, abrasion resistant, no
discoloration, el. conductive
Reinforcements: Thermoplast braids. Type UTS additionally with
galvanised steel helix
Cover: EPDM, black, el. conductive, resistant against weather and
ageing, flame resistant
Working pressure up to: 16 bar
Temperature range: - 40° up to + 100° C
Further properties:
• Steaming out for cleaning and sterilisation permissable up to
130° C for max. 30 minutes (open ends)
• Meets EN 12115, Ω /T

DOWNLOAD the catalog card
