As suction and discharge hose for containers, rail tankers, tankers and
fixed installations. The steel helix ensures that the hose keeps in shape
during suction and gravity operations, even with tight bending radii.
ELAFLON PLUS FEP With helix
Blue-white-red coloured spiral and abrasion resistant continuous
embossing
Chemicals
- Inner lining: FEP, seamless, transparent, smooth bore, electrically
non-conductive - Reinforcements: Textile braids, form SD additionally with
galvanised steel helix - Cover: EPDM, electrically conductive, light grey with OHM
conductive stripe (up to DN 50) or black (DN 63 – 100). Abrasion
and flame resistant, resistant against weather and ageing - Working pressure up to: 16 bar
- Temperature range: - 30° C up to + 100° C, briefly up to 130° C
- Further properties:
• This high performance hose combines added flexibility and
robustness of an elastomer hose with the chemical resistance
associated with a Fluoropolymer hose lining
• The lining of ELAFLON PLUS FEP is resistant to all mediums
except e. g. chlorine trifluoride, oxygen difluoride and molten
alkali metals. Limited chemical resistance (20° C) chlorine and
fluorine gas
• The very smooth FEP lining prevents the settling of residues
and allows easy cleaning – an advantage with frequent medium
changes
• Meets EN 12115
