Breweries, distillereies, distilleries, ex zones, filling machines, other
installations in the brewing, beverage and spirits industry, wine press
houses
PURPURSCHLANGE® PLUS CONDUCTIVE
Alcohol <20%, alcohol >20%, beer, buttermilk, cheese, chocolate, citric
acid, cottage cheese, dairy ice cream, dough, egg yolk, fats, fishmeal,
foodstuffs, fruit ice cream, fruits, gelatine, granulate and powder media,
ice, juice, ketchup, lactic acid, milk, milk powder, mustard, oils, rice
pudding, sparkling wine, spirits, sugar syrup, tallow, vinegar, wine,
yoghurt
Blue wavy line on a red background, applied in a spiral “Continental
PURPURSCHLANGE® PLUS CONDUCTIVE FDA glass/fork symbol BfR EG
1935/2004 2023/2006 Made in Germany
- Inner lining: UPE, white, absolutely neutral to taste and odour,
non-porous, smooth, with black coiled OHM conductive stripe - Reinforcements: Synthetic fibres with integrated steel wire helix
- Cover: Spezial elastomer, red, fabric patterned, abrasion resistant,
resistant to ozone, weather and UV, with black coiled OHM
conductive stripe - Working pressure up to: 16 bar / 232 psi
- Temperature range: from -30 °C / -22 °F up to +95 °C / +203 °F
up to +110 °C / +230 °F (max. 60 minutes) - Dampable up to: +130 °C / +266 °F (max. 30 minutes)
- Further properties:
• 3 years warranty
• Can be cleaned by CIP installations
• Electrically conductive, R < 109 Ω, through the hose wall
• Flexible
• Recommended fittings system PAGUFIX®
• Resistant to commonly used cleaning and disinfecting products
• Suitable for pure alcohol up to 100%
• Suited to use in ex-zones
