Extra flexible mandrel built chemical suction and delivery hose designed
for acids, bases, ketons, aldheyds, esters, aromatic and aliphatic
hydrocarbons (limited resistance to chlorinated hydrocarbons). Also
suitable for animal or vegetable foodstuffs and alcoholic drinks. Complies
with F.D.A. standards and with BfR recommendations XXI cat. 3. For a
correct use of the hose please consult our Chemical Resistance Chart.
SUPERIOR/HF SBB
THOR UHMWPE CHEMICAL S/D FOOD QUALITY - W.P. 16 BAR - 225 PSI
(in yellow letters)
acids, bases, ketons, aldheyds, esters, aromatic and aliphatic
hydrocarbons, animal or vegetable foodstuffs, alcoholic drinks
- Inner lining: UHMWPE, white, smooth, food quality
- Reinforcements: Synthetic plies, helix wire embedded, antistatic
wire - Cover: Special blue rubber, abrasion, ozone and weather resistant.
Smooth with fabric impression - Working pressure up to: 16 bar
- Temperature range: Cleaning up to 110°C for max. 30 Min in open
system. Temperature and concentration of the transported medium:
refer to chemical resistance chart - Further properties:
The hose resists to a tensile stress of 4.000 N (approx. 400 kg)
with a temporary diameter shrinking of 3,5%.
