Type HD

‘Yellow Band’ high pressure fuelling hose without helix for reel
operation. Ideal for all petroleum based products. Corresponds to EN
1761. Can be calibrated according to European regulations. Approved to
German military standard VG 95 955 Typ D. Corresponds to EN 12115.

Yellow bands every 4 mtr. Continuous, vulcanised embossing as per
example above.

Petroleum based products

Inner lining: Nitrile rubber (NBR) black, no fuel-solubility
Reinforcements: Two low tensile textile braids for extreme low
volume increase under pressure
Cover: Chloroprene (CR), black, el. conductive
Working pressure up to: 25 bar
Temperature range: - 30° up to + 90° C
(temporarily up to 110° C)
Electrical conductivity: < 106 Ohm
Further properties:
• The lining is resistant to swelling, solubility and discolouration.
It is flexible at low temperatures.
• The cover is resistant to abrasion and weathering and
furthermore provides a very good low temperature flexibility
• Meets the material group NBR 1 of the EN 12115
